MX225-HS


A fast, high resolution detector for X-ray science applications. Consists of a 3 x 3 tiled array of frame-transfer CCD modules, with 225 x 225mm² square active area, tiled without gaps in the imaging area. Full resolution is 5760 x 5760 pixels.

Category: .
Description
This 225mmx225mm square X-ray area detector has several specialized modes. Besides the standard mode described in the specs and parameter sections, Turbo, Low-Noise and High Dynamic Range (HDR) modes are also user controlled.
Technical Specifications
Type

9 FT-CCDs bonded to fiber-optic tapers
Sensor

Proprietary Rayonix
frame-transfer CCD
Active Imaging Surface

225mmx225mm , 50625mm²
Dark Current

<0.01e⁻/pixel/sec @ 2048 x 2048 pixels

Dead Time Between Images

as short as 300 milliseconds with frameshift option
DQE

0.8 for 8KeV to 12keV radiation
Fiber-optic Taper Demagnification Ratio

2.6:1
Full Well Capacity

360,000e-/pixel @ std. 2×2 binning
Phosphor

40μm thick, custom options available
PSF (FWHM) Depends on Phosphor Option Chosen

100μm with standard phosphor
Readout Electronics (# of Channels)

144 channels
Readout Noise

8e⁻/pixel standard mode
4e⁻/pixel low noise mode
Sensitivity (Gain)

9e⁻/12keV photon
Sensor Operating Temperature

-80°C
Cooling

Closed-cycle refrigeration
User-Configurable Imaging Parameters
1 X 1
Readout Speed

Pixel Size

Frame Size

 2.5 frames/second

39μm

5760 x 5760 pixels
2 X 2
Readout Speed

Pixel Size

Frame Size
 10 frames/second

78μm

2880 x 2880 pixels
3 X 3
Readout Speed

Pixel Size

Frame Size

 20 frames/second

117μm

1920 x 1920 pixels
4 X 4
Readout Speed

Pixel Size

Frame Size

  33 frames/second

156μm

1440 x 1440 pixels
5 X 5
Readout Speed

Pixel Size

Frame Size

  47 frames/second

195μm

1152 x 1152 pixels
6 X 6
Readout Speed

Pixel Size

Frame Size

  62 frames/second

234μm

960 x 960 pixels
8 X 8
Readout Speed

Pixel Size

Frame Size

  92 frames/second

312μm

720 x 720 pixels
10 X 10
Readout Speed

Pixel Size

Frame Size

  123 frames/second

390μm

576 x 576 pixels
Physical Dimensions
Detector Head
Height x Width x Depth

Approximate Weight

 50cm x 41cm x 46cm

57kg
Electronics / Cooling Assembly
Height x Width x Depth

Approximate Weight
175cm x 64cm x 64cm
215kg
