Overview
The MX series is the only large format mosaic X-ray detector without gaps in the images. These detectors are suitable for protein crystallography, powder diffraction, X-ray imaging and many other applications. Rayonix MX series detectors have been installed at most synchrotrons worldwide for many years.

Available are various configurations of FOT (fiber-optic taper) coupled modules. The MX series of detectors use 3 x 3 or 4 x 4 arrays of fused fiber-optic taper elements to make a very large active area. Unlike other multi-element detectors, the images produced have no gaps between the modules. Rayonix factory calibration is permanent and suitable for all X-ray sources.

Category: MX series
Share
Description
Overview
The MX series is the only large format mosaic X-ray detector without gaps in the images. These detectors are suitable for protein crystallography, powder diffraction, X-ray imaging and many other applications. Rayonix MX series detectors have been installed at most synchrotrons worldwide for many years.

Available are various configurations of FOT (fiber-optic taper) coupled modules. The MX series of detectors use 3 x 3 or 4 x 4 arrays of fused fiber-optic taper elements to make a very large active area. Unlike other multi-element detectors, the images produced have no gaps between the modules. Rayonix factory calibration is permanent and suitable for all X-ray sources.

Technical Highlights
The first large format X-ray mosaic detectors without gaps in the images for protein crystallography, low energy X-ray crystallography, small or wide angle X-ray scattering (SAXS), X-ray imaging and many other applications demanding high resolution imaging.
  • Higher resolution
  • No gaps
  • Excellent linearity
  • Low noise
  • Factory calibration
Technical Specifications

Technical Specifications

Type

9 CCDs bonded to fiber-optic tapers

Fiber-optic Taper Demagnification Ratio

2:7:1

Phosphor

Standard 40μm thick, custom options available

PSF (FWHM) Depends on Phosphor Option Chosen

100μm with standard phosphor, 65μm with 25μm phosphor

Active Imaging Surface

225mm x 225mm
50,625mm²

Sensor Operating Temperature

-80°C

Readout Electronics (# of Channels)

18

Readout Noise

10e⁻/pixel

Dark Current

<0.01e⁻/pixel/second (12keV)

DQE

0.8

Sensitivity (Gain)

6e⁻/12keV photon

Full Well Capacity

360ke⁻/pixel
(at standard binning, 2 x 2)

Cooling

Closed-cycle refrigeration

User-Configurable Imaging Parameters
1 X 1
Readout Speed

Pixel Size

Frame Size

2 seconds

37μm

6144 x 6144 pixels

2 X 2
Readout Speed

Pixel Size

Frame Size

 1 second

73μm

3072 x 3072 pixels

3 X 3
Readout Speed

Pixel Size

Frame Size

0.5 second

110μm

2046 x 2046 pixels

4 X 4
Readout Speed

Pixel Size

Frame Size

0.3 second

146μm

1536 x 1536 pixels

Physical Dimensions
Detector Head
Height x Width x Depth

Approximate Weight

46cm x 32cm x 40cm

52kg

Electronics / Cooling Assembly
Height x Width x Depth

Approximate Weight

117cm x 64cm x 64cm
215kg
